Title: Orthocentre |
Grade: 7-a Lesson: S3-L7 |
Explanation: |
Step | Type | Explanation | Answer |
---|---|---|---|
1 |
Problem |
|
|
2 |
Given |
vertices of triangle are \$(3, 1), (0, 4)\$ and \$(–3, 1)\$. |
|
3 |
Assume |
Let \$A(1,–2), B(3,1)\$ and \$C(–2,3)\$. Let AD and BE be the altitudes. |
|
4 |
Step |
Slope of line joining points B \$(0, 4)\$ and \$(-3, 1)\$ |
\begin{align} \require{cancel} \text{Slpoe of BC } &= \frac{1 - 4}{-3 - 0} \\ &= \frac{-3}{-3} \\ &= 1 \\ \end{align} |
5 |
Step |
AD is perpendicular to BC. If the slope of altitude AD = -1, then the equation of altitude AD is |
\begin{align} \require{cancel} && y - 1 &= -1(x – 3) \\ \Rightarrow && y - 1 &= -x + 3 \\ \Rightarrow && x + y - 4 &= 0 \tag{1} \\ \end{align} |
6 |
Step |
Slope of line joining points A \$(3,1)\$ and C \$(-3 ,1)\$ |
\begin{align} \require{cancel} \text{Slpoe of AC } &= \frac{1 - 1}{-3 -3} \\ &= \frac{0}{6} \\ &= 0 \\ \end{align} |
7 |
Step |
Therefore slope of the altitude BE \$= \frac{-1}{0} = \infty \$, since BE is perpendicular to AC. Equation of BE is |
\begin{align} \require{cancel} y – 4 &= \frac{-1}{0} (x – 0) \\ 0 &= -x + 0 \\ x &= 0 \tag{2} \\ \end{align} |
8 |
Step |
Solving equation (1) and (2) \$x + y -4 = 0\$ and \$x = 0\$, we get |
\begin{align} \require{cancel} y - 4 = 0 \\ y = 4 \\ \end{align} |
9 |
Step |
Answer |
The ortho centre is \$(0, 4)\$. |
